| 1, power supply: AC220V, 50Hz; |
| 2, cross arm range (radius): 750mm (can be configured according to the requirements of the hospital) |
| 3, horizontal rotation angle: 0～340°, horizontal arm and terminal box can be rotated separately or simultaneously; |
| 4, net weight ≥120kg; |
| 5, instrument platform: dry section configuration:3layer; wet section configuration: 2 layers; height adjustable, rounded corner anti-collision design,Aluminum alloy sheet, surrounded by international standard side rails, |
| 6、Gas interface configuration: dry section configuration: 2 oxygen, 2 negative pressure suction, 1 air;Wet section configuration: oxygen 2 pcs, negative pressure suction 2 pcs, air 2 pcs a, the color and shape of the interface are different, it has the function of preventing wrong connection; b. The number of insertion and removal is more than 20,000; c. The use of secondary sealing, with three states (pass , Break, pull), can be repaired with air; |
| 7, power socket: dry section configuration: 6, 220V, 10A; wet section configuration: 7, 220V, 10A |
| 8, equipotential grounding terminal: dry section configuration: 1; wet section configuration: 1 |
| 9, stainless steel adjustable infusion rod holder: dry section configuration: 1; wet section configuration: 1 |
| 10, dry segment configuration: network and telephone interface each, wet segment configuration: network interface: 1 |
| 10, the main material is made of high-strength aluminum alloy profiles; |
| 11, the surface treatment adopts electrostatic spraying; |
| 12, ceiling-mounted installation, stable and firm. |
